Furutech FA-aS22




Enter Quantity --->>

    View your shopping cart

View CategoryView Similar Products

The Furutech FA-aS22 bulk interconnect cable (aka Furutech FA Alpha S22) is the newest bulk interconenct cable by Furutech, and replaces the Furutech FA-220. This is Furutech's best/flagship bulk interconnect cable offering. The Furutech FA-aS22 uses Furutech’s α (Alpha) OCC conductor, which is known by audiophiles to be amongst the best conductor materials available for sound reproduction. Furutech's α (Alpha) OCC copper is made with high-purity oxygen-free copper using a special Ohno Continuous Casting process. Unlike regular OFC, almost all of the grain boundaries of this high-purity OCC have been removed at the micron level through a special casting process unique to Furutech.

The FA Alpha S22 uses a shielded twisted pair geometry, with each conductor insulated with a special grade of polypropylene. Each conductor leg is stranded @ 60 strands of 33 AWG material, for an aggregate AWG of about 15.3 AWG. The FA Alpha S22 then uses cotton dampening material, a paper sheath, an inner PVC sheath with carbon dampening particles, braided shield, and outer PVC sheath. Sold by the FOOT.

SPECIFICATIONS

Conductor Material: α(Alpha) OCC
Construction(pcs/mm): 60 strands / ψ0.18 mm
Insulation Material: Audio grade Polypropylene (Red, White insulation)
Conductor Diameter: 2.6mm
Twisting Method : 2 Cores Twisted Together
Filler Material: Audio grade damping cotton
Barrier Layer Material: Stabilizer Paper Tape (Wrap)
Shield Material: ψ0.12mm α (Alpha) Conductor wire braid
Inner Sheath Material: Audio grade flexible PVC (Black) Incorporating damping carbon particles
Sheath Material: Audio grade Flexible PVC (Purple blue)
Nom. Thickness: 1.0mm
Overall Diameter Approx.: 9.0mm

RATING

Max. Conductor Resistance: Ω / km 13.2 (JISC3005 6 20℃)
Min. Insulation Resistance MΩ / km >100 (JISC3005 9.1 20℃)
CAPACITANCE: PF/M 84.1 at 1KHz
IMPEDANCE: Ω 37.7 at 10 MHz
INDUCTANCE: uH/M 1.55 at 1KHz
Dielectric Strength: V /1 min. AC 1000 (JISC3005 8)
